Durable Blow Molding Ball Drain Valve for PE, PVC, and ABS - Efficient and Reliable Solution for Drainage

  • Durable Blow Molding Ball Drain Valve for PE, PVC, and ABS - Efficient and Reliable Solution for Drainage
  • Durable Blow Molding Ball Drain Valve for PE, PVC, and ABS - Efficient and Reliable Solution for Drainage
  • Durable Blow Molding Ball Drain Valve for PE, PVC, and ABS - Efficient and Reliable Solution for Drainage
  • Durable Blow Molding Ball Drain Valve for PE, PVC, and ABS - Efficient and Reliable Solution for Drainage
Place of Origin China
Brand Name Hongum
Certification 3A、CE、SGS approval
Model Number Customized
Minimum Order Quantity 10 pcs
Price 30-50 USD/pcs
Packaging Details Standard
Delivery Time 7-15 days
Payment Terms Wire Transfers, letters of credit, Western Union, Paypal, T/T, L/C
Supply Ability 1000 pcs/month
Product Details
Process Blow Molding, Rotational Molding, Injection Molding Blister Fecal System Sealing System
Material PE, PVC, ABS Dimension Ø250 Mm H=400mm
Connection Method Buckle Type Ball Shaped
Highlight

PE Ball Drain Valve

,

PVC Ball Drain Valve

,

Blow Molding Ball Drain Valve
Leave a Message
Product Description

Durable Blow Molding Ball Drain Valve for PE, PVC, and ABS - Efficient and Reliable Solution for Drainage





Quick details:



1. Material: PE, PVC, ABS
2. Process: Blow molding, rotational molding, injection molding
3. Application: Blister manure pig farm
4. Tolerance: ±0.05
5. Features: Good toughness, wear resistance, high strength
6. Product specification: 200mm
7. Product classification: Plastic building materials
8. Implement quality standard: 90001
9. Color: Red, black
10. Pressure range: PN50
11. Model: DN250
12. Connection method: Buckle
13. Type: Straight-through



Durable Blow Molding Ball Drain Valve for PE, PVC, and ABS - Efficient and Reliable Solution for Drainage 0Durable Blow Molding Ball Drain Valve for PE, PVC, and ABS - Efficient and Reliable Solution for Drainage 1Durable Blow Molding Ball Drain Valve for PE, PVC, and ABS - Efficient and Reliable Solution for Drainage 2Durable Blow Molding Ball Drain Valve for PE, PVC, and ABS - Efficient and Reliable Solution for Drainage 3



Specifications:



Prod. No. Product Name Dimension
19.21.22.01 Stub with stay Type 1 Ø250 mm H=400mm
19.21.22.02 Extension with stay Ø250 mm H=480
(Gluing)
19.21.22.03 Apollo-Ball Set Ø250 mm
19.21.22.04 Stopper black b m/s Ø315mm
19.21.22.05 Stopper Black m/s Ø250mm
19.21.22.06 Sealing ring for Plug Ø200 mm
19.21.22.07 Sealing ring for Plug Ø250 mm
19.21.22.08 Air Escape Valve Ø110 mm
19.21.22.09 Air Escape Valve Ø160 mm
19.21.22.10 Gluing stub for Air Ø110/250 mm
Escape
19.21.22.11 Gluing stub for Air Ø110/200 mm
Escape
19.21.22.12 Mounting air valve Ø110 mm
19.21.22.13 Mounting air valve Ø160 mm
19.21.22.14 Double-socket, Grey Ø110 mm
19.21.22.15 Double-socket, Grey Ø160 mm
19.21.22.16 Overflow Valve Ø160 mm
19.21.22.17 PVC Pipe ( Made in Ø200 mm
China) Gluing T=4.9mm
19.21.22.18 PVC Pipe ( Made in Ø250 mm
China) Gluing T=6.2mmcc





Introduction:



Our company specializes in the production of manure leak plugs for pig farms, including sewage pipe plugs and blister manure plugs. With the modernization of the pig industry, the new blister manure treatment method has replaced the previous manual processing of manure, saving time and increasing efficiency.



Blistered manure is an effective method of flushing manure out of pig houses and directing it to sedimentation or septic tanks through drainage ditches. This can be accomplished through various methods such as sprinkler water flushing, gate type water flushing, and self-flow water flushing. The advantages of this method include simple equipment, high efficiency, and improved sanitation, reducing the risk of epidemic diseases.



Our manure leak plugs are designed to be compatible with blistered manure systems used in farrowing and nursery houses, limited stalls for pregnant sows, and slatted floors in fattening pig houses. By using our products, you can improve the overall sanitation and efficiency of your pig farm operations.



Durable Blow Molding Ball Drain Valve for PE, PVC, and ABS - Efficient and Reliable Solution for Drainage 4Durable Blow Molding Ball Drain Valve for PE, PVC, and ABS - Efficient and Reliable Solution for Drainage 5





Our service:



1. Packaging is neutral packing or customized packing.



2. We will reply you within 24 hours.



3. We will also provide you with good after-sales service.



4. OEM or ODM orders are welcomed.



5. Trial orders are acceptable.



6. High quality and factory price.



7. 100% ensured the quality.
