Marine Floating High Pressure Hydraulic Hose Corrosion Resistant
Product features:
1. The hose is made of special synthetic rubber, which has excellent oil resistance, heat resistance and aging resistance.
2. The hose has high bearing pressure and excellent pulse performance.
3. The tube body is tightly combined, soft to use, and less deformed under pressure.
4. The hose has excellent bending resistance and fatigue resistance.
5. The length of the steel wire braided hose is large, and the fixed length is generally 20 meters. It can be produced up to tens of meters or even more than 100 meters.
Structure:
The marine high-pressure oil pipeline is composed of a steel wire wound skeleton layer and internal and external oil-resistant and corrosion-resistant synthetic rubber.
Uses:
Marine high-pressure oil hoses are used for the transportation of submarine natural gas, petroleum and other media.
Quick details:
| Category | Marine high pressure oil hose |
| Product Specifications | 6mm-1000mm |
| Application Range | Petroleum, marine, oil pipeline |
|
Length Size
|
Can be customized according to engineering requirements |
| Working pressure | 1-100MPA |
Specifications:
| Hose Specifications |
Inner Diameter (mm) |
Outer diameter of steel wire layer (mm) |
Hose outer diameter (mm) |
Working Pressure | Test Pressure | Burst Pressure |
Min. Bend Radius (mm) |
Reference Weight KG/M |
|||
|
Model-ID-Pressure- Force |
Mpa | Psi | Mpa | Psi | Mpa | Psi | |||||
| 2sp-152-8 | 152±2.0 | 173±3.0 | 180±4.0 | 8.0 | 1159 | 16.0 | 2318 | 24.0 | 3477 | 2280 | 18 |
| 2sp-203-8 | 203±2.0 | 225±3.0 | 232±4.0 | 8.0 | 1159 | 16.0 | 2318 | 24.0 | 3477 | 3050 | 24 |
| 2sp-254-8 | 254±2.0 | 280±3.0 | 288±4.0 | 8.0 | 1159 | 16.0 | 2318 | 24.0 | 3477 | 3810 | 30 |
| 2sp-305-8 | 305±2.0 | 330±3.0 | 338±4.0 | 8.0 | 1159 | 16.0 | 2318 | 24.0 | 3477 | 4510 | 36 |
| 4sp-152-16 | 152±2.0 | 184±3.0 | 192±4.0 | 16.0 | 2318 | 32.0 | 4636 | 48.0 | 6955 | 2580 | 24 |
| 4sp-203-16 | 203±2.0 | 236±3.0 | 243±4.0 | 16.0 | 2318 | 32.0 | 4636 | 48.0 | 6955 | 3350 | 31 |
| 4sp-254-16 | 254±2.0 | 291±3.0 | 299±4.0 | 16.0 | 2318 | 32.0 | 4636 | 48.0 | 6955 | 4110 | 39 |
| 4sp-305-16 | 305±2.0 | 341±3.0 | 350±4.0 | 16.0 | 2318 | 32.0 | 4636 | 48.0 | 6955 | 4810 | 47 |
