Rubber Diaphragm Material Ingersoll Pneumatic Rubber Diaphragm Sealing Diaphragm Pumps Replacements Parts

Ingersoll Pneumatic Rubber Diaphragm Sealing Diaphragm PUMPS REPLACEMENTS PARTS

Introduction:

Pneumatic diaphragm pump sheet material is divided into: neoprene rubber, nitrile butadiene rubber, fluorinated rubber, EPDM rubber, Polyperfluoroethylene propylene, and so on.

QBY Pneumatic Diaphragm Pump Diaphragm:

Pneumatic diaphragm pump is the use of compressed air as power source, for all kinds of liquid with particles, high viscosity, easy to play, highly toxic liquid and corrosive liquid and gelatinous liquid do not need to fill water, can be drained to absorb, fire and explosion-proof. With self-priming pump, impurity pump, shield pump, submersible pump, mud pump and all other functions, pump body material is aluminum alloy, cast iron, stainless steel, engineering plastics, fluorine plastic, QBY pneumatic diaphragm pump diaphragm with nitrile rubber, neoprene rubber, fluorine rubber, PTFE to meet the needs of different users. It has been adopted by domestic petroleum, chemical, electronic, ceramic, textile system and other units, placed in various special occasions, used to pump a variety of medium which conventional pump can not pump, have achieved satisfactory results.

General Pneumatic Diaphragm Pump Diaphragm:

The diaphragm of the pneumatic diaphragm pump is usually made of NBR rubber or natural rubber. The reasons for choosing the above two kinds of rubber are on the one hand because of the high cost performance, and on the other hand because the material characteristics of the two materials are more suitable for the production environment, such as oil resistance, wear resistance, etc. , can effectively deal with the corrosion and wear of the diaphragm caused by such an environment, so that the pneumatic diaphragm can effectively prolong the service life.

Materials:

• Neoprene: an excellent general purpose diaphragm suitable for non-corrosive liquid transport areas such as sewage treatment, tap water or sea water. It is flexible, economical and versatile.

• Neoprene: an excellent general purpose diaphragm suitable for non-corrosive liquid transport areas such as sewage treatment, tap water or sea water. It is flexible, economical and versatile.

• Nitrile rubber: used for the transport of petroleum and oil liquids, such as leaded gasoline, diesel oil, hydraulic oil, kerosene oil, etc. Transport non-corrosive gravity and consistency of the slurry selection of the diaphragm is better.

• Fluorinated rubber: the best choice of extremely high temperature fluid pump, high temperature resistance of 176 degrees, can also transport some corrosive liquid, such as essence, chlorinated hydrocarbons and strong corrosive acid, alkali and other media.

• EPDM: the best choice for extreme cryogenic pumps, as low as -51 degrees, can also be used to pump dilute acid or low corrosive liquids.

• Polyperfluoroethylene propylene: high price, strong corrosion resistance, flexibility is better than PTFE, suitable for low temperature corrosive media.

• Polyperfluoroethylene propylene: high price, strong corrosion resistance, flexibility is better than PTFE, suitable for low temperature corrosive media.

• PTFE: also known as , which has the characteristics of the acid alkali resistance, resistance to a variety of organic solvents, almost insoluble in all solvents, non-stick coating can continuous use at 260 ℃, with a high temperature 290-300 ℃, low friction coefficient, wear resistance and excellent chemical stability. So the PTFE is widely used in the diaphragm pump of a material, of course, the price is also the highest in all materials. Generally used in high temperature and strong acid and alkali and other strong corrosion areas.

Characteristics:

Oil resistance, good elasticity, anti aging, strong sealing, tear resistance, acid and alkali resistance, corrosion resistance, high and low temperature resistance, long service life, wear resistance.
