Pressure Regulator Rubber Rolling Diaphragm Seal FKM CR EPDM

  • Pressure Regulator Rubber Rolling Diaphragm Seal FKM CR EPDM
  • Pressure Regulator Rubber Rolling Diaphragm Seal FKM CR EPDM
  • Pressure Regulator Rubber Rolling Diaphragm Seal FKM CR EPDM
Place of Origin China
Brand Name Hongum
Certification 3A、CE、SGS approval
Model Number GMA-SM3
Minimum Order Quantity 50 PCS
Price USD 5-150/PCS
Packaging Details PE+carton box
Delivery Time 7~15 working days
Payment Terms Wire Transfers, letters of credit, Western Union, Paypal, T/T, L/C
Supply Ability 5000PCS/Month
Product Details
Name Rolling Diaphragm, Blowing Electromagnetic Pulse-valve Diaphragm Material FKM, CR, EPDM
Usage Scene Gas Pressure Regulator, Pressure Regulating Valve Color Black Or Customized
Packing Plastic+carton Model GMA-SM3 Or Custom
Temperature -20° To 80° Service Life ≥1000000 Times
Highlight

Rubber Rolling Diaphragm Seal

,

EPDM Rubber Fabric Diaphragm

,

Pressure Regulator Valve Rubber Diaphragm
Leave a Message
Product Description

Pressure Regulator Rubber Rolling Diaphragm Seal Valve Rubber Diaphragm





​Rolling Diaphragm Product Overviews:



The rolling diaphragm is shaped like a top hat in the free state. It is made of rubber with silk cloth. The middle hole on the top is used for installing the valve stem. In order to fit, fix and seal, the top and bottom can be equipped with 0 type edge changer, or the bottom surrounding with mounting hole.



Product Materials NBR,NR, etc.
Operating Temperature -20℃~80℃
Service Life ≥1000000 times
Usage Scenario Gas pressure regulator





Pressure Regulator Rubber Rolling Diaphragm Seal FKM CR EPDM 0Pressure Regulator Rubber Rolling Diaphragm Seal FKM CR EPDM 1





Pressure Regulator Rubber Rolling Diaphragm Seal FKM CR EPDM 2





Rolling Diaphragm​ Introduction:



In the design of some medium and low pressure regulators, in order to solve the problem of unbalanced pressure regulator disc and improve the performance of the regulator, the method of installing a balanced diaphragm is often used. Installing a balancing diaphragm increases the differential pressure between the inlet and outlet pressures of the regulator. In the voltage regulator industry, it is called a balanced diaphragm in terms of use, and it is called a rolling diaphragm in rubber, instrumentation, machinery and other industries.



The rolling diaphragm is in the shape of a top hat in the free state. It is made of rubber with silk cloth. The top middle hole is used to install the valve stem. In order to install, fix and seal, the top and bottom can have O-ring edges. Or in the form of fixing holes around the bottom edge.





Rolling Diaphragm​ Characteristics:



• Fabrication technics of textile makes the product tear resistance stronger

• High quality raw materials ensure the excellent performance of the material itself





Rolling Diaphragm Specifications:



Rolling Diaphragm Model

Outer diameter(mm)

Inside diameter(mm)

 Base diameter(mm) Height(mm) Thickness(mm) Pressure
GMA-20 38 22 17 21 0.6 0.1-1MPa
GMA-201 45 40 33 28 0.7 0.1-1MPa
GMA-202 49 37 26 22 0.7 0.1-1MPa
GMA-21S 61 50 39 29 0.7 0.1-1MPa
GMA-21 63 53 43 33 0.7 0.1-1MPa
GMA-22 65 50 45 51 0.7 0.1-1MPa
GMA-23 80 72 55 35 0.7 0.1-1MPa
GMA-24 94 74 64 45 0.7 0.1-1MPa
GMA-31 96 90 79 90 0.8 0.1-1MPa
GMA-301 98 80 70 34 1.5 0.1-1MPa
GMA-311 120 102 94 60 0.8 0.1-1MPa
GMA-32 140 93.2 83.2 56 1 0.1-1MPa
GMA-33 184 167 155 80 1 0.1-1MPa
GMA-34 216 170 142 40 1.1 0.1-1MPa
GMA-SMI 118 108 100 72 0.9 0.1-1MPa
GMA-SM2 95 87 80 90 0.9 0.1-1MPa
GMA-ST 155 137 110 128 0.8 0.1-1MPa





Our service:



1. Packaging is neutral packing or customized packing.

2. We will reply you within 24 hours.

3. We will also provide you with good after-sales service.

4. OEM or ODM orders are welcomed.

5. Trial orders are acceptable.

6. High quality and factory price.

7. 100% ensured the quality.





Tags:

Air Compressor Diaphragm

Valve Rubber Diaphragm

Rubber Rolling Diaphragm
