Compressed Air Single-acting Linear Actuator Rotary Cylinder Diaphragm Rubber Rolling Pump Valve Rubber Diaphragm
Rolling Pump Valve Rubber Diaphragm Product Overviews:
Compared with the rubber corrugated diaphragm used in regulating valves, the rolling diaphragm has a higher pressure resistance.
Almost all the pressure load of the rolling diaphragm is supported by the piston, and only a small part of the liquid pressure or gas pressure is supported by the narrow area of the diaphragm, so the rolling diaphragm can obtain greater pressure bearing capacity and higher thrust.
The rubber diaphragm is mainly used in the pneumatic film actuator, which can convert the control signal (DC4～20mA or 1-5V) output by the controller into the linear displacement of the valve stem through the (intelligent) electric valve positioner and the pneumatic film actuator. Or valve shaft angular displacement accessories.
| Product Materials |
NBR,NR, ETC. |
| Operating Temperature |
-20℃~80℃ |
| Service Life |
≥1000000 times |
| Usage Scenario |
Gas pressure regulator |
Rolling Pump Valve Rubber Diaphragm Characteristcs:
Fabrication technics of textile makes the product tear resistance stronger
High quality raw materials ensure the excellent performance of the material itself
Rolling Pump Valve Rubber Diaphragm Specifications:
| Rolling Diaphragm |
Model |
Outer diameter(mm)
|
Inside diameter(mm)
|
Base diameter(mm) |
Height(mm) |
Thickness(mm) |
Pressure |
| GMA-20 |
38 |
22 |
17 |
21 |
0.6 |
0.1-1MPa |
| GMA-201 |
45 |
40 |
33 |
28 |
0.7 |
0.1-1MPa |
| GMA-202 |
49 |
37 |
26 |
22 |
0.7 |
0.1-1MPa |
| GMA-21S |
61 |
50 |
39 |
29 |
0.7 |
0.1-1MPa |
| GMA-21 |
63 |
53 |
43 |
33 |
0.7 |
0.1-1MPa |
| GMA-22 |
65 |
50 |
45 |
51 |
0.7 |
0.1-1MPa |
| GMA-23 |
80 |
72 |
55 |
35 |
0.7 |
0.1-1MPa |
| GMA-24 |
94 |
74 |
64 |
45 |
0.7 |
0.1-1MPa |
| GMA-31 |
96 |
90 |
79 |
90 |
0.8 |
0.1-1MPa |
| GMA-301 |
98 |
80 |
70 |
34 |
1.5 |
0.1-1MPa |
| GMA-311 |
120 |
102 |
94 |
60 |
0.8 |
0.1-1MPa |
| GMA-32 |
140 |
93.2 |
83.2 |
56 |
1 |
0.1-1MPa |
| GMA-33 |
184 |
167 |
155 |
80 |
1 |
0.1-1MPa |
| GMA-34 |
216 |
170 |
142 |
40 |
1.1 |
0.1-1MPa |
| GMA-SMI |
118 |
108 |
100 |
72 |
0.9 |
0.1-1MPa |
| GMA-SM2 |
95 |
87 |
80 |
90 |
0.9 |
0.1-1MPa |
| GMA-ST |
155 |
137 |
110 |
128 |
0.8 |
0.1-1MPa |
