DB112 DB112/G Diaphragm For Mecair Pulse Valve VNP212 VNP312 VNP412
Brief introduction of electromagnetic pulse valve diaphragm:
The electromagnetic pulse valve diaphragm is a whole piece of rubber diaphragm installed with a riveting head used to block the compressed air pipeline or the air outlet of the blocking valve, a venting unloading hole and a bolt hole for fixed support around it. It is the key control part in the electromagnetic pulse valve.
DB112 ( DB112/G ) Diaphragm ( Membrane ) for Mecair pulse valve VNP212, VEM212, VNP312, VEM312, VNP412, VEM412; NBR material is standard, working temperature range is -5 to +80 ℃; material is optional, for high temperature, working temperature range is -10 to +120 ℃. Pulse valve, also called diaphragm valve acts as a "switch" for compressed air in the dust clean blowing system for pulse bag filters. It is controlled by the electric signals from the pulse jet control device. This system cleans the filter bags cluster by cluster with high-pressure blowing to keep the pressure resistance of the baghouse within a pre-set range, and thus ensure the processing capability and the dust-collecting efficiency of the baghouse.
Features:
Fabrication technics of textile makes the product tear resistance stronger
High quality raw materials ensure the excellent performance of the material itself
| Product Materials | NBR,NR |
| Operating Temperature | -20℃~80℃ |
| Service Life | ≥1000000 times |
| Usage Scenario | Bag filter devices /precipitator equipment |
Application:
Referred to the dust collector, it applies to waste gas dust filtering of Cement plant, Steel mill, Power station, Electrolytic
aluminium factory, Incineration plant, crushing mixing conveying of Chemical plant, crushing mixing sieving grinding of
Pharmaceutical plant, raw material mixing packing of Paper mill, bagging mixing of Dyeing mill, crushing gagging conveying and mixing of Fertilizer plant, crushing plasticzation conveying of Kilns, sawing polishing filing of Log mill, etc.
Structural properties:
The operating temperature range and pressure range of the diaphragm itself depends on the type of rubber, fabric and structure. The diaphragm can work under the conditions of -50~100 degrees Celsius and 0.4~0.8MPa; the fluororubber and silicone rubber diaphragms can work under the conditions of -80~232 degrees Celsius. Chlorohydrin rubber diaphragm can work under the pressure of 0.4~0.8MPa, has good air tightness, anti-aging, and its life is equal to that of engine overhaul.
