Customized Exhaust Gas Rubber Air Pipe Aging Resistance Ozone Resistance
| Place of Origin | CHINA |
|---|---|
| Brand Name | HONGUM |
| Certification | SGS CE |
| Model Number | Customized |
| Minimum Order Quantity | 10meters |
| Price | USD 5-40/Meter |
| Packaging Details | Colorful Nylon Tape Wrapped Coils / Carton/ Wooden Plante or as Requestment |
| Delivery Time | 5-20days |
| Payment Terms | L/C, T/T |
| Supply Ability | 50000 meters per week |
Product Details
| Name | Exhaust Gas Rubber Air Pipe | Aplication | Extraction Of Dust, Exhaust Gas, Ash |
|---|---|---|---|
| Product Features | Aging Resistance, Ozone Resistance | Material | Rubber |
| Specifications | 6mm-1000mm | Temperature | -20℃--45℃ |
| Pressure | 0-50 MPA | Length | Customized |
| Highlight | Aging Resistance Rubber Air Pipe,Ozone Resistance Rubber Air Pipe,Customized Exhaust Gas Pipe |
||
Product Description
Customized Exhaust Gas Rubber Air Pipe Aging Resistance Ozone Resistance
1. Product structure:
The cloth conveying hose is composed of an inner rubber layer, a multi-layer cloth winding layer and an outer rubber layer.
The cloth suction hose is composed of an inner rubber layer, a multi-layer cloth winding layer, a spiral steel wire reinforcement layer and an outer rubber layer.
2. Product Features:
The hose has the characteristics of small outer diameter tolerance, excellent oil resistance and heat resistance, light weight, soft and durable hose body, etc. The small burst pressure of the hose is four times the working pressure.
3. Product use:
Various types of cloth conveying (or suction) hoses are made of corresponding materials according to different conveying media. The product structure is reasonable in design, high in quality, and durable. Flexible hoses for various liquid viscous fluids and powdered solids and other material media.
Quick details:
| Category | Rubber duct |
| Product Specifications | 6mm-1000mm |
| Area of Application | Extraction of dust, exhaust gas, ash |
|
Length Size |
Can be customized according to engineering requirements |
| Working Pressure | 1kg-10kg |
Divided according to use:
1. Water delivery hose: suitable for general water delivery, used in the environment of -20℃--45℃.
2. Air hose: suitable for conveying compressed air and inert gas, and used in the environment of -20℃--45℃.
3. Oil-resistant rubber hose: suitable for conveying conventional oil and used in the environment of -20℃--45℃.
4. Heat-resistant hose: suitable for conveying water below 100℃.
Steam hose: suitable for conveying hot water or saturated steam below 170°C.
5. Dilute acid and alkali resistant hose: convey dilute acid and alkali solution with a concentration below 40%, and use it in the environment of -20℃--45℃.
6. Sandblasting hose: suitable for air pressure sandblasting and rust removal and grinding on metal surfaces.
7. Suction and drainage, oil hose: working pressure 1.0-1.5MPa (4 times the safety factor).
8. Food hose for transporting and sucking: It is used to discharge and absorb liquids such as beer, beverage, edible oil, etc. at room temperature, and the taste and color will not change, which meets the hygienic requirements of food rubber.
Technical parameters of general-purpose cloth conveying hose and suction hose:
| Cloth hose parameters | |||||||||
| Inner diameter (mm) | Work pressure | Corresponding burst pressure | Hose length | ||||||
| Nominal size | Tolerance | (Mpa) | (Mpa) | Size (m) | Tolerance(mm) | ||||
| 13 | 0.8 | 0.5 | 0.7 | 1.0 | 2.0 | 2.8 | 4.0 | 20 | 200 |
| 16 | 0.8 | 0.5 | 0.7 | 1.0 | 2.0 | 2.8 | 4.0 | 20 | 200 |
| 19 | 0.8 | 0.5 | 0.7 | 1.0 | 2.0 | 2.8 | 4.0 | 20 | 200 |
| 25 | 0.8 | 0.5 | 0.7 | 1.0 | 2.0 | 2.8 | 4.0 | 20 | 200 |
| 32 | 1.2 | 0.3 | 0.5 | 0.7 | 1.2 | 2.0 | 2.8 | 20 | 200 |
| 38 | 1.2 | 0.3 | 0.5 | 0.7 | 1.2 | 2.0 | 2.8 | 20 | 200 |
| 51 | 1.2 | 0.3 | 0.5 | 0.7 | 1.2 | 2.0 | 2.8 | 20 | 200 |
| 64 | 1.5 | 0.3 | 0.5 | 0.7 | 1.2 | 2.0 | 2.8 | 20 | 200 |
| 76 | 1.5 | 0.3 | 0.5 | 0.7 | 1.2 | 2.0 | 2.8 | 20 | 200 |
Our service:
1. Packaging is neutral packing or customized packing.
2. We will reply you within 24 hours.
3. We will also provide you with good after-sales service.
4. OEM or ODM orders are welcomed.
5. Trial orders are acceptable.
6. High quality and factory price.
7. 100% ensured the quality.
