75-250 Size Fitting Synthetic Fibre Braided Air Hose NR SBR Air Compressor Hose OEM 6mm-1000mm

  • 75-250 Size Fitting Synthetic Fibre Braided Air Hose NR SBR Air Compressor Hose OEM 6mm-1000mm
  • 75-250 Size Fitting Synthetic Fibre Braided Air Hose NR SBR Air Compressor Hose OEM 6mm-1000mm
  • 75-250 Size Fitting Synthetic Fibre Braided Air Hose NR SBR Air Compressor Hose OEM 6mm-1000mm
  • 75-250 Size Fitting Synthetic Fibre Braided Air Hose NR SBR Air Compressor Hose OEM 6mm-1000mm
Place of Origin CHINA
Brand Name HONGUM
Certification SGS CE
Model Number Customized
Minimum Order Quantity 10meters
Price USD 5-40/Meter
Packaging Details Colorful Nylon Tape Wrapped Coils / Carton/ Wooden Plante or as Requestment
Delivery Time 5-20days
Payment Terms L/C, T/T
Supply Ability 50000 meters per week
Product Details
Name Synthetic Fibre Braided Air Hose NR SBR Air Compressor Hose Cover Fiber
Specifications 6mm-1000mm Product Material NR, SBR
Temperature -20℃~+60℃(-4℉to+140℉) Characteristics Wear Resistance
Color Black Or Customized Length Size Can Be Customized According To Engineering Requirements
Highlight

SBR Braided Air Hose

,

6mm Braided Air Hose

,

Steel Braided Air Compressor Hose
Leave a Message
Product Description
75-250 Size Fitting Synthetic Fibre Braided Air Hose NR SBR Air Compressor Hose OEM 6mm-1000mm


Introduction:

Air hose, also known as compressed air hose, rubber duct, air belt, etc.

Uses: Widely used in mining, construction, engineering, shipbuilding, steel production and other industries to transport air, inert gas and water. , details:

Tube: NR and SBR synthetic rubber, black.

Reinforcing layer: high-strength synthetic fibers, single-layer/double-layer fiber weaving or winding reinforcement.

Cover: NR and SBR synthetic rubber, the color is black or red, yellow, blue, etc.

Performance characteristics: wear resistance, aging resistance, ozone resistance, high pressure bearing, soft, lightweight, good bending performance, small deformation, beautiful appearance.

Temperature range: -20℃~+60℃(-4℉to+140℉).





Quick details:



Category Air Hose
Product Specifications 6mm-1000mm
Scope of Application Suction of dust, waste gas, ash, gas extraction
Length Size Can be customized according to engineering requirements





75-250 Size Fitting Synthetic Fibre Braided Air Hose NR SBR Air Compressor Hose OEM 6mm-1000mm 075-250 Size Fitting Synthetic Fibre Braided Air Hose NR SBR Air Compressor Hose OEM 6mm-1000mm 175-250 Size Fitting Synthetic Fibre Braided Air Hose NR SBR Air Compressor Hose OEM 6mm-1000mm 275-250 Size Fitting Synthetic Fibre Braided Air Hose NR SBR Air Compressor Hose OEM 6mm-1000mm 3





Specifications:



Inner diameter (mm) Outer diameter (mm) Working pressure (bar) Burst pressure (bar) Weight (kg/m) Length of each roll (m)
12.0 30.0 10.0 30.0 0.80 120
16.0 24.0 10.0 30.0 0.32 120
20.0 30.0 10.0 30.0 0.55 120
22.0 32.0 10.0 30.0 0.59 120
25.0 34.0 10.0 30.0 0.56 120
30.0 41.5 10.0 30.0 0.88 120
30.0 42.0 10.0 30.0 0.95 120
35.0 48.0 10.0 30.0 1.15 120
40.0 54.5 10.0 30.0 1.46 120
45.0 61.0 10.0 30.0 1.77 120
51.0 69.0 10.0 30.0 2.32 120





Inside Diametermm

 Layer of Cloth

Helix Steel

Wire Diameter

 Length of Fitting mm Length of Hose

Nominal Size

Tolerance

 (layer)

(mm)

 Size Tolerance Size m Tolerance mm
38 1.2 2 3 2.0 75 10 10 150
51 1.2 3 4 2.6 100 15 10 150
64 1.5 3 4 2.6 100 15 10 150
76 1.5 4 5 2.6 100 15 10 150
89 1.5 4 5 3.2 100 15 10 150
102 2.0 4 5 3.2 125 20 10 150
127 2.O 5 6 3.2 125 20 10 150
152 2.0 5 6 4.0 150 20 10 150
203 2.5 6 7 5.0 200 25 10 150
254 2.5 7 8 5.0 200 25 10 150
305 2.5 7 8 5.0 250 25 10 150





Inside Diameter mm

Working Pressure

MPa

Corresponding Burst Pressure

MPa

 Length of Hose

Nominal Size

Tolerance

Size

m

Tolerance

mm
13 0.8 0.5 0.7 1.0 2.0 2.8 4.0 20 200
16 0.8 0.5 0.7 1.0 2.0 2.8 4.0 20 200
19 0.8 0.5 0.7 1.0 2.0 2.8 4.0 20 200
25 0.8 0.5 0.7 1.0 2.0 2.8 4.0 20 200
32 1.2 0.3 0.5 0.7 1.2 2.0 2.8 20 200
38 1.2 0.3 0.5 0.7 1.2 2.O 2.8 20 200
51 1.2 0.3 0.5 0.7 1.2 2.O 2.8 20 200
64 1.5 0.3 0.5 0.7 1.2 2.0 2.8 20 200
76 1.5 0.3 0.5 0.7 1.2 2.0 2.8 20 200





Our service:



1. Packaging is neutral packing or customized packing.



2. We will reply you within 24 hours.



3. We will also provide you with good after-sales service.



4. OEM or ODM orders are welcomed.



5. Trial orders are acceptable.



6. High quality and factory price.



7. 100% ensured the quality.
