Fiber Cover High Pressure High Temperature Resistance Air Hose 6mm-1000mm
  • Fiber Cover High Pressure High Temperature Resistance Air Hose 6mm-1000mm
  • Fiber Cover High Pressure High Temperature Resistance Air Hose 6mm-1000mm
  • Fiber Cover High Pressure High Temperature Resistance Air Hose 6mm-1000mm
  • Fiber Cover High Pressure High Temperature Resistance Air Hose 6mm-1000mm

Fiber Cover High Pressure High Temperature Resistance Air Hose 6mm-1000mm

Place of Origin CHINA
Brand Name HONGUM
Certification SGS CE
Model Number Customized
Product Details
Name:
Fiber Cover High Pressure High Temperature Resistance Air Hose
Characteristics:
Wear Resistance, Aging Resistance, Ozone Resistance
Material:
NR, SBR
Cover:
Fiber, Etc
Temperature:
-20℃~+60℃(-4℉to+140℉)
Specifications:
6mm-1000mm
Color:
Black
Size:
Customized
Highlight:

Fiber High Temperature Air Hose

,

SBR High Temperature Air Hose

,

6mm High Pressure Air Hose

Payment & Shipping Terms
Minimum Order Quantity
10meters
Price
USD 4-50/Meter
Packaging Details
Colorful Nylon Tape Wrapped Coils / Carton/ Wooden Plante or as Request
Delivery Time
5-20days
Payment Terms
L/C, T/T
Supply Ability
50000 meters per week
Product Description
Fiber Cover High Pressure High Temperature Resistance Air Hose 6mm-1000mm


Introduction:


Air hose, also known as compressed air hose, rubber duct, air belt, etc.

Uses: Widely used in mining, construction, engineering, shipbuilding, steel production and other industries to transport air, inert gas and water. , details:

Tube: NR and SBR synthetic rubber, black.

Reinforcing layer: high-strength synthetic fibers, single-layer/double-layer fiber weaving or winding reinforcement.

Cover: NR and SBR synthetic rubber, the color is black or red, yellow, blue, etc.

Performance characteristics: wear resistance, aging resistance, ozone resistance, high pressure bearing, soft, lightweight, good bending performance, small deformation, beautiful appearance.

Temperature range: -20℃~+60℃(-4℉to+140℉).



Fiber Cover High Pressure High Temperature Resistance Air Hose 6mm-1000mm 0Fiber Cover High Pressure High Temperature Resistance Air Hose 6mm-1000mm 1Fiber Cover High Pressure High Temperature Resistance Air Hose 6mm-1000mm 2Fiber Cover High Pressure High Temperature Resistance Air Hose 6mm-1000mm 3





Specifications:



Inner diameter (mm) Outer diameter (mm) Working pressure (bar) Burst pressure (bar) Weight (kg/m) Length of each roll (m)
12.0 30.0 10.0 30.0 0.80 120
16.0 24.0 10.0 30.0 0.32 120
20.0 30.0 10.0 30.0 0.55 120
22.0 32.0 10.0 30.0 0.59 120
25.0 34.0 10.0 30.0 0.56 120
30.0 41.5 10.0 30.0 0.88 120
30.0 42.0 10.0 30.0 0.95 120
35.0 48.0 10.0 30.0 1.15 120
40.0 54.5 10.0 30.0 1.46 120
45.0 61.0 10.0 30.0 1.77 120
51.0 69.0 10.0 30.0 2.32



120
